Wood
- Structural grade certified SPF (Spruce, Pine, Fir), SYP (Southern Yellow Pine) Douglas Fir and Yellow Cedar from Canadian Wood — high strength-to-weight ratio.
- Coated with Termiguard® – colourless, oil-borne, bio-wood preservative for
prevention and control of termites, fungus and borers — certified by The Institute of Wood Science and Technology - Twin coats of Plantag® oil, from Plantag GMBH, Germany — for water resistance and long-term wood surface and grain protection. We also apply Bono® Natural Oil for external frames, offering enhanced UV resistance and long-lasting protection against weathering.
Weight
590 g/m² (17.4 oz/sq. yd) EN ISO 2286-2
Length x Width
40 lm (43.74 yd) x 180cm (70.9")
Thickness
0.45 mm • 450 microns
Tensile strength
220/220 daN/5cm EN ISO 1421
Tear strength
25/22 daN • 56/49 lbs
Adhesion
7/7 daN/5cm EN ISO 2411
Surface finish treatment
PVDF Varnish both sides
Flame retardancy rating
M2/NF P 92-507 B1/DIN 4102-1, M2/UNE 23.727-90 Class e 2/UNI 9177-87 VKF 5.3/SN 198898 BS 7837 Schwerbrennbar Q1 - Tr1/ONORM A 3800-1 Method 1/NFPA 701 Method 2/NFPA 701 CSFM T19 Class A/ASTM E84 CAN ULC S109 AS/NZS 1530.2 AS/NZS 1530.3 Group 1/AS NZS 3837 T2/EN15619
Euroclass
B-s2, DO EN 13501-1
Thermal resistance (R-Value)
0.71 sqm/W
Colour options
33 Colour options
Main features
Satin finish • Reinforced dirt resistance • Easy cleaning
• Dimensional stability • Longevity • Filters 100% of UVB rays [UPF 50+ for all colors] • Long term mechanical resistance • 10 year warranty
• Dimensional stability • Longevity • Filters 100% of UVB rays [UPF 50+ for all colors] • Long term mechanical resistance • 10 year warranty
Weight
380gsm (11.21 oz/sqyd) IS 7016 - Part 1
Width
150cm (59.06")
Strip-breaking strength
Warp/weft - 175 kgf/5cm IS 7016 - Part 1
Tongue-tear strength
25 kgf IS 7016 - Part 3
Vertical flammability
Pass
Adhesion
3.5kgf/2.5cm IS 7016 - Part 5
Surface finish treatment
Lacquer coating on both sides
Flame retardancy rating
Fire retardant lacquer coating, 24 secs after-flame time
Char length
265mm
Colour
Light sand colour - Easy cleaning
Material
Cross linked closed cell polyethylene-10mm
(ASTM C 1427)
(ASTM C 1427)
Density
30Kg/M3 (ASTM D 3575)
Thermal conductivity (K) W/m.K @ 46 deg C
0.0382 (ASTM C 518)
Thermal Resistance (R) ft²-F-hr/btu (Heat flow down)
25.34 (ASTM C 518)
Smoke development Index
5 (ASTM E 84)
Fire Characteristics: Surface spread and propagation
Class 'O' (BS 476, part 6&7
Fungal & Bacterial resistance
Zero growth (ASTM E 2180)
Tensile strength
2.51 kgf/cm2 (ASTM D 3575)
Elongation at break
133.20% (ASTM D 2863)
Dome
Dome material
Non-tinted clear polycarbonate glass
Coating
UV stabilizer surface treatment
Thickness
5mm
Sizes
4' and 6' dia (1.21m and 1.82m) 4' dia (1.21m) domes are used in 20' (6m) and 24' (7m) yurts 6' dia (1.82m) domes are used in 32' (10m) yurt.
Dome hardware
Secured with stainless steel eye bolts, nylock nuts and grade 316 stainless steel brackets. Stainless steel hinge and grade 316 stainless steel springs.
Spindle
Grade 316 steel, CNC routed.12mm aluminum spindle winder for opening dome. Remote operated dome opener available as an accessory.
Blackout blinds
Remote operated blackout blind for the dome, made of high quality fabric retracting into a skylight frame. Available as an accessory.
Tension Cable
- Our tension cables are made of super-strong galvanized aircraft cable with PVC sleeve, terminating in stainless steel turnbuckle and steel clamps.
Hardware
The lattice-rods are fixed to the platform using 3mm thick custom fabricated grade 316 stainless steel I-plate.
M6 x 50 T30 Pan head
The rafters are connected to the tono ring using custom-fabricated galvanized stainless steel grade 316 brackets.
M6 x 50 T30 Pan head
Fabric is integrated to the yurt using custom extruded powder coated aluminum single and double channels bent according to the radius of the yurt.
Custom-fabricated
Custom-extruded
Custom-extruded
The lattice rods are fixed to the door/window frame using stainless steel grade 316 brackets.
M6 x 50 T30 Pan head
Density
480-800 kg/m3 (30 - 50lb/cft)
Bending strength
70-100 MPa (10k-14500 psi) CSA O86, ASTM D198
Modulus of elasticity
10k-12k MPa (5850-8700 psi) CSA O86, ASTM D198
Compression strength
40-60 MPa (5850-8700 psi) CSA O86, ASTM D198
Natural durability
Moderate - high resistance to decay
Workability
Good with machines, good finishes
Colour
Reddish brown - yellowish brown
Grain texture
Straight grain, medium texture
Dimensions
6 x 4'7"
Weight
Approx. 15-22kg
Thickness
50mm frame, 5mm glass
Material
UPVC - White (standard, colours available)
Thermal, U-Value
Approx. 1.2-1.8 W/sqmK
Fixed Glass
8mm clear toughened
Custom-designed accessories for
The Out Factory yurts
- A custom-built wooden frame designed to securely hold your air conditioner in place. It can be easily mounted onto the yurt wall or integrated with a window frame.
- Perfect for adding AC units without compromising the structure or aesthetics of your yurt.
- Upgrade your yurt with a remote-controlled dome opener that lifts the dome up to 6 inches, allowing warm air to escape and improving natural ventilation inside the yurt.
- By default, all yurts come with a manual dome opener. This remote version adds convenience and better climate control — especially useful in hotter climates or for guest comfort.
- A motorized blackout blind designed to cover the central dome from inside the yurt. It blocks out sunlight completely, making it perfect for restful naps or late mornings — even under bright afternoon skies.
- These are specially crafted wooden rhombus panels designed to perfectly align with the rhombus-shaped openings in the yurt wall. They act as an elegant mounting base for your standard electrical switch plates, blending functionality with natural aesthetics.
Inclusions & Exclusions
- • Yurt wall, roof and dome
• Manual dome opener
• For 20' (6m) and 24' (7m) yurts, 1 door with frame 2 windows with frames
• For 32' (10m) yurts 1 door with frame 4 windows with frames
- • Yurt platform and flooring
• Electrical, plumbing and sanitary fixtures
• Interior partitions
• Furniture and furnishings
